Product description

Information

AN 605 Clamps for Photocell are typically mounted on adjusting rods and are usually used in conjunction with round threaded body photocell sensor units.
Sensor normally is suppled with two securing nuts. The sensor body with one nut is placed through the clamp hole, then the second nut is replaced on the body. Sensor is placed in ideal position, and both nuts are then tightened to secure sensor to clamp.

Specification

Clamp
  • Black
  • Reinforced polyamide plastic

Fasteners
  • Stainless steel AISI 304

RoHS compliant

Technical drawing

3D
Hide technical drawing
AN 605 Clamps for Photocell sketch

Part Options / Table

Show / Hide columns

Metric

Dimensions in: Inch (change to Metric)
DF
Fits Round Dimension
DC
Fits Square Dimension
B 10V 8
B 12V 10
B 14V 12

Build & Price

3D Product Configurator
DF

Selected Part

Total US Dollars (net)
$6.22
In Stock: 59
In Stock
Please note our quantity discounts (US Dollars).
MinMaxPrice
19$6.22
1024$5.70
2549$5.19
≥ 50$4.67
Prop 65: -
Please contact our Sales Department for more information.
RoHS: -
No details on RoHS compatibility are available at this time. Please contact our Sales Department for more information.
Weight: -
If the weight is not listed, please contact our Sales Department for more information.
